QUINT-PS-100-240AC/24DC/40
Power supply unit
INTERFACE
Data sheet
102315_en_02
? PHOENIX CONTACT 2010-04-23
1
Description
Features
QUINT POWER power supply units for plant and special
engineering reliably start heavy loads with high inrush
currents using the POWER BOOST. Thanks to the wide-
range input and extensive package of approvals, they can be
used in all sectors of industry the world over. The switching
output or floating relay contact are used for remote
diagnostics.
–
–
–
–
–
–
Universal power supply unit with an extensive product
range, including special versions and accessories
Can be used worldwide in all industrial sectors due to a
wide-range input and an international approval package
High level of operational reliability thanks to high MTBF
> 500,000 h, long mains buffering times > 20 ms
Reliable starting of heavy loads with high inrush currents
through the POWER BOOST power reserve
Active function monitoring through switching output and
preventive function monitoring through floating relay
contact for remote diagnosis
Parallel connection possible for increased performance
and redundancy
DANGER OF EXPLOSION!
Only remove equipment when it is disconnected and not in the potentially explosive area.
DANGER
Components with dangerously high voltage and high stored energy are located in the device!
Never carry out work on live parts!
Depending on the ambient temperature and the load, the housing can become very hot!
Make sure you always use the latest documentation.
It can be downloaded from the product at www.phoenixcontact.net/catalog .
